Company Advantages
· The material, design, and production of Naier spiral vertical wind turbine comply with international regulations.
· The product is assured to meet the highest quality standards in the industry.
· As the professional spiral vertical wind turbine leading manufacturer, we only offer the qualified products.
Model |
NE-3kG-GJ |
NE-5kG-GJ |
NE-7.5kG-GJ |
NE-10kG-GJ |
NE-15kG-GJ |
NE-20kG-GJ |
NE-30kG-GJ |
Rated power |
3kw |
5kw |
7.5kw |
10kw |
15kw |
20kw |
30kw |
Rated voltage |
48v/120v |
96v/220v |
96v/380v |
120v/380v |
120v/380v |
220v/380v |
220v/380v |
Start-up wind speed |
2.5m/s |
||||||
Rated wind speed |
10m/s |
10m/s |
10.5m/s |
10.5m/s |
11m/s |
11m/s |
11m/s |
Survival wind speed |
45m/s |
||||||
Wheel diameter |
4.8m |
5.4m |
5.8m |
6.48m |
7.86m |
9.28m |
11.82m |
Number of blades |
3 |
||||||
Blades material |
FRP |
||||||
Flange Connection |
DN125 |
DN150 |
DN200 |
DN250 |
|||
Generator type |
Three phase permanent magnet AC synchronous generator |
||||||
Magnet material |
NdFeB |
||||||
Generator case |
Casting aluminum alloy |
||||||
Control system |
Intelligent Mechanic main shaft brake+Electromagnet control |
||||||
Speed regulation |
Automatic direction |
||||||
Working temperature |
-40°C - 70°C |
||||||
Design life |
25 y |
Advantages of G systems
Advantages one
● Adopt low speed permanent magnet generator , design of direct drive gearless transmission .
● Having multiple certifications such as CE and ISO14001, as well as multiple intellectual property patents.
● Multi-level safety protection such as Intelligent mechanical brake, electromagnetic braking and automatically adjust windward direction, with independent intellectual property rights of the company, ensures the safe and stable operation of the wind turbine in extreme weather conditions based on real-time monitoring data.
Advantages two
The motor casing is integrally formed by mold casting, the material is aluminum alloy, engine compartment is made of high-strength alloy steel and rolled up into shape as a whole, which has the advantages of good heat dissipation and light weight. the surface adopts strict anti-corrosion measures, making it durable and durable.
Advantages three
The blades of the wind turbine are precisely manufactured by a new technology and equipped with optimized aerodynamic shape design and structural design, making installation convenient, wind energy utilization coefficient high, and increasing annual power generation.
Advantages four
● Professional magnetic circuit design, low motor starting torque, reduced starting wind speed, and improved wind energy utilization rate.
● Adopting humanized design, the overall components are lightweight, flexible, and convenient for lifting, installation, and disassembly.
● Suitable for small wind farms, smart grids, and other applications.
Case display
Company Features
· Yixing Naier Wind Power Technology Co., Ltd is one of the leading suppliers in China with a focus on designing and manufacturing product spiral vertical wind turbine.
· Our company is equipped with product specialists. They have a wealth of knowledge and experience gained through many years of product development in the spiral vertical wind turbine industry. We have worked with people here and countless companies in China (and other regions). By emphasizing the importance of building a true relationship with each customer to ensure that we thoroughly understand all aspects of our business, we have received many repetitive purchases. We have professional employees. What makes them stand out from the crowd is the ability to provide in-depth, expert knowledge of individual geographic trades and spiral vertical wind turbine markets.
· Sustainability operates around the clock, all over the site in our company. For example, a variety of policies, such as the provision of special buses or the encouragement of cycling, are in place at our different facilities to cut the number of car journeys into work each day.
Product Details
spiral vertical wind turbine's details are presented below. They help better know the product.
Application of the Product
The spiral vertical wind turbine developed and produced by our company can be widely used in various industries and professional fields.
Naier insists on providing customers with reasonable solutions according to their actual needs.
Product Comparison
Compared with other spiral vertical wind turbine, the spiral vertical wind turbine produced by Naier has the following advantages and features.
