Product details of the spiral wind mill
Quick Detail
While manufacturing Naier spiral wind mill, our skilled and qualified experts work with complete determination. This product is thoroughly inspected as per the quality guidelines. Our spiral wind mill has a wide range of applications. spiral wind mill from Naier is the best seller in the market.
Product Information
Compared with similar products, Naier's spiral wind mill has the following advantages.
|
Model |
NE-1kQ10-Cla |
NE-2kQ10-Cla |
NE-3kQ10-Cla |
NE-5kQ10-Cla |
NE-1kQ10-Max |
NE-2kQ10-Max |
NE-3kQ10-Max |
NE-5kQ10-Max |
|
Rated power |
1kw |
2kw |
3kw |
5kw |
1kw |
2kw |
3kw |
5kw |
|
Rated voltage |
48v/96v |
120v/220v |
220v/380v |
48v/96v |
120v/220v |
220v/380v |
||
|
Start-up wind speed |
2m/s |
2.5m/s |
2.5m/s |
3m/s |
||||
|
Rated wind speed |
11m/s |
11.5m/s |
12m/s |
11m/s |
11.5m/s |
12m/s |
||
|
Survival wind speed |
35m/s |
|||||||
|
Wheel diameter |
2m |
2.5m |
3m |
3.6m |
2m |
2.5m |
3m |
3.6m |
|
Flange Connection |
DN125 |
DN200 |
DN125 |
DN200 |
||||
|
Number of blades |
3 |
|||||||
|
Blades material |
Casting aluminum alloy |
|||||||
|
Generator type |
Three phase maglev generator |
Three phase permanent magnet AC synchronous generator |
||||||
|
Magnet material |
NdFeB |
|||||||
|
Generator case |
Casting aluminum alloy |
|||||||
|
Control system |
Electromagnet |
|||||||
|
Speed regulation |
Automatically adjust windward direction |
|||||||
|
Working temperature |
-20°C - 60°C |
|||||||
Product Advantages
Advantages one
● Adopting an exterior structural design with independent intellectual property rights,perfect for breeze start,the effect of breeze power generation,machine volume small,light weight,with beautiful appearance,low operating vibration.
● The shell of the magnetic levitation generator is made of high-strength aluminum alloy and is integrally die-cast through a mold,the outer rotor generator casing is made of high-strength alloy steel and rolled up into shape as a whole,high mechanic strength,good heat dissipation performance.equipped with special stator and rotor design,effectively reducing running resistance torque,improve the utilization rate of wind energy.
Advantages two
● The wind wheel drives the blades using high-quality aluminum alloy thick plates,safe and firm;at the same time, the surface of the blade is sprayed with plastic or oxidation treatment,enhanced corrosion resistance, attractive and durable,colors can be customized according to customer requirements.
● High speed blades are molded using high-quality aluminum profile molds for overall die-casting,high installation accuracy,stronger typhoon resistance,ensure safe and reliable operation of the fan.
Advantages three
● The intelligent tracking technology of wind power generation efficiency is adopted,effectively regulating current and voltage,high power generation conversion rate.
● Low noise during operation,omnibearing automatic windward,adopting humanized flange installation design,suitable for various occasions.the use of distributed wind power generation layout can effectively solve the problem of customers' electricity difficulties.
Company Introduction
Located in wu xi, Yixing Naier Wind Power Technology Co., Ltd is a standardized enterprise. We are responsible for the production, sales and trade of Horizontal axis small wind turbin,Vertical axis small wind turbine,Permanent magnetic generator. Naier has always provided customers with the best service solutions and has won high praise from customers. Consulting and order from friends of all walks of life are welcomed!
