Model |
NE-1000L1 |
NE-1500L1 |
NE-2000L1 |
NE-2000L2 |
NE-2500L2 |
NE-3000L2 |
|
Rated power |
1000W |
1500W |
2000W |
2000W |
2500W |
3000W |
|
Rated voltage |
48v/96v |
48v/96v |
96v/120v |
96v/220v |
||
|
Start-up wind speed |
2.5m/s |
|||||
|
Rated wind speed |
10m/s |
10.5m/s |
11m/s |
10m/s |
10.5m/s |
11m/s |
|
Survival wind speed |
45m/s |
|||||
|
Wheel diameter |
2.58m |
2.88m |
3.18m |
3.45m |
3.69m |
3.99m |
|
Number of blades |
3 |
|||||
|
Blades material |
FRP |
|||||
|
Flange Connection |
DN50 |
DN80 |
||||
|
Generator type |
Three phase permanent magnet AC synchronous generator |
|||||
|
Magnet material |
NdFeB |
|||||
|
Generator case |
Casting aluminum alloy |
|||||
|
Control system |
Electromagnet |
|||||
|
Speed Control mode |
Yaw automatically |
|||||
|
Working temperature |
-40°C - 70°C |
|||||
|
Design life |
25 y |
|||||
Advantages of L-series system
Advantages one
● Adopt low speed permanent magnet generator, direct drive gearless transmission design.
● Having CE, ISO14001 multiple certifications and multiple intellectual property patents.
● With the company's independent intellectual property rights of electromagnetic brake and automatic cornering and other multi-level security protection, ensure the safe and stable operation of the fan in extreme weather according to real-time monitoring data.
Advantages two
The motor casing is integrally formed by casting aluminum profile molds, good heat dissipation, Light weight; The cabin is made of high-strength aluminum material, mold casting integrated molding, Apply excellent anti-corrosion measures, High mechanical properties and durability, The tail wing adopts a folded tail design, According to different wind directions automatic sideways to the wind, stronger typhoon resistance, safe and reliable operation.
Advantages three
The wind turbine blades are formed through precision manufacturing using a new process, with optimized aerodynamic shape design and structural design, easy installation, high utilization coefficient of wind energy, increased annual power generation.
Advantages four
● Professional magnetic circuit design, low motor starting torque, reduced starting wind speed, improving wind energy utilizationefficiency.
● Adopt humanized design, lightweight overall components, nimble, easy to hoist, install and disassemble.
● Suitable for small wind farms, smart grids, and other applications.
Case display
Company Advantages
· The materials Naier spiral wind turbine uses are selected from reliable suppliers.
· This product has complete functions, complete specifications and is in great demand worldwide.
· This product has great market opportunities and huge growth prospects.
Company Features
· Naier is developed by Yixing Naier Wind Power Technology Co., Ltd with the great influence in the field of spiral wind turbine.
· Yixing Naier Wind Power Technology Co., Ltd keeps prosperity in its technical level of spiral wind turbine and has attracted many cooperators.
· We always stick to the high ethical standards in business dealings. We will make our behaviors in compliance with laws and regulations, and avoid any kind of breaking promises behaviors.
Application of the Product
The spiral wind turbine produced by Naier has a wide range of applications.
With professional engineers and technicians in our company, Naier is able to provide one-stop and comprehensive solutions for customers.
